ESP8266 WiFi Module + 4x2 stackable header for ESP8266 + AU Stock

US $5.65
SKU:
BC-2211
Shipping:
Calculated at checkout
Current Stock:
12
Quantity:

 WARNING: NEVER USE 5V. 5V will damage the board. Use 3.3V for the module.

You know that ESP8266 is not breadboard friendly. So, we have made one that help you fix the module on your breadboard. You will get 4x2 8-pin stackable header for ESP8266 module. With the header, you can easily stack the module on the breadboard. NOTE: It is handmade, we will test it before we send.

The ESP8266 WiFi module is a self contained SOC with integrated TCP/IP protocol stack that can give any microcontroller access to your WiFi network.

The ESP8266 is capable of either hosting an application or offloading all Wi-Fi networking functions from another application processor. Each ESP8266 module comes pre-programmed with an AT command set firmware, meaning, you can simply hook this up to your Arduino device and get about as much WiFi-ability as a WiFi Shield offers (and that’s just out of the box)! The ESP8266 module is an extremely cost effective board with a huge and ever growing community.

This module has a powerful enough on-board processing and storage capability that allows it to be integrated with the sensors and other application specific devices through its GPIOs with minimal development up-front and minimal loading during run time. Its high degree of on-chip integration allows for minimal external circuitry, including the front-end module, is designed to occupy minimal PCB area. The ESP8266 supports APSD for VoIP applications and Bluetooth co-existance interfaces, it contains a self-calibrated RF allowing it to work under all operating conditions, and requires no external RF parts.

There is an almost limitless fountain of information available for the ESP8266, all of which has been provided by amazing community support. In the Documents section below you will find many resources to aid you in using the ESP8266, even instructions on how to transforming this module into an IoT (Internet of Things) solution!

Note: The ESP8266 Module can only connnect with 3.3V system directly. if you want connecit with a 5V system, you need a  Logic Level Converter.

Features:

  • 802.11 b/g/n
  • Wi-Fi Direct (P2P), soft-AP
  • Integrated TCP/IP protocol stack
  • Integrated TR switch, balun, LNA, power amplifier and matching network
  • Integrated PLLs, regulators, DCXO and power management units
  • +19.5dBm output power in 802.11b mode
  • Power down leakage current of <10uA
  • Integrated low power 32-bit CPU could be used as application processor
  • SDIO 1.1 / 2.0, SPI, UART
  • STBC, 1×1 MIMO, 2×1 MIMO
  • A-MPDU & A-MSDU aggregation & 0.4ms guard interval
  • Wake up and transmit packets in < 2ms
  • Standby power consumption of < 1.0mW (DTIM3)

Documents:

Package includes:

  • 1 x ESP8266 WIFI module
  • 1 x 4x2 Female Header

We are selling all the components required to get started with ESP8266 WIFI module (CLICK HERE)

esp8266-accessories
